GIGABYTE USB 3.0 Motherboards

Модели

Intel – X58A Series

	GA-X58A-UD7	GA-X58A-UD5	GA-X58A-UD3R

Модель	GA-X58A-UD7	GA-X58A-UD5	GA-X58A-UD3R
Процессор	Intel Core i7 Processors	Intel Core i7 Processors	Intel Core i7 Processors
Сокет	LGA1366	LGA1366	LGA1366
QPI/FSB	6.4GT/s, 4.8GT/s	6.4GT/s, 4.8GT/s	6.4GT/s, 4.8GT/s
Чипсет	Intel X58 + ICH10R	Intel X58 + ICH10R	Intel X58 + ICH10R
Встроенная графика	-	-	-
Графический интерфейс	4*PCI-E 2.0 x16 slot (2x16 or 4x8)	4*PCI-E 2.0 x16 slot (2x16 or 4x8)	4*PCI-E 2.0 x16 slot (2x16 or 4x8)
Память	Dual Channel DDR3 2200/1333/1066/800	Dual Channel DDR3 2200/1333/1066/800	Dual Channel DDR3 2200/1333/1066/800
Слоты памяти	6*DDR3 (Max 24 GB)	6*DDR3 (Max 24 GB)	6*DDR3 (Max 24 GB)
Слоты расширения	1PCI + 2PCI-Ex1	1PCI + 2PCI-Ex1	1PCI + 2PCI-Ex1
ATA connector	2SATA 6Gb/s 10SATA 3Gb/s + 1*PATA	2SATA 6Gb/s 10SATA 3Gb/s + 1*PATA	2SATA 6Gb/s 10SATA 3Gb/s + 1*PATA
RAID	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10
Audio	HD Audio, 8-channel	HD Audio, 8-channel	HD Audio, 8-channel
IEEE 1394	3*IEEE 1394a	3*IEEE 1394a	3*IEEE 1394a
USB	10USB 2.0, 2USB 3.0	10USB 2.0, 2USB 3.0	10USB 2.0, 2USB 3.0
LAN	2*Gigabit LAN (Teaming Support)	2*Gigabit LAN (Teaming Support)	1*Gigabit LAN (Teaming Support)
BIOS	DualBIOS™	DualBIOS™	DualBIOS™
Характеристики	USB 3.0, SATA 6Gb/s, 3x USB power, 24 phase power, Ultra Durable 3, Dynamic Energy Saver 2, ATI CrossFireX, SLI, Debug LED, Dolby Home Theater, Precision OV, eSATA/ USB combo, Hybrid SILENT-PIPE 2, Quick Boost	USB 3.0, USB 3x power , SATA 6Gb/s, 12 phase, Smart6, Ultra Durable 3, Dynamic Energy Saver 2, 3 Way SLI, ATI CrossFireX, Dolby Home Theater, Precision OV, Debug LED, EuP Ready	USB 3.0, USB 3x power , SATA 6Gb/s, Smart6,Ultra Durable 3, Dynamic Energy Saver 2, 3 Way SLI, ATI CrossFireX, Dolby Home Theater, Precision OV, EuP Ready
ПО в комплекте	EasyTune 6, Norton™ Internet Security	EasyTune 6, Norton™ Internet Security	EasyTune 6, Norton™ Internet Security
Форм фактор (мм)	ATX (305x244)	ATX (305x244)	ATX (305x244)

Norton™ Internet Security
Fast, comprehensive, and up-to-the-minute protection against online threats. It safeguards your computer, identity, and home network without slowing you down.
It sets a new standard for speed and makes online shopping, banking, and browsing safer and more convenient than ever.

U : 2 oz copper PCB design D : All solid capacitor design
*Product features may vary by model. *Motherboard models may vary based on local distribution.
*Please refer to GIGABYTE website for CPU support information.
